This file documents version 0.15 of the mod_authz_ldap
module. For details about the change history of the module, please
consult the ChangeLog.
This Apache LDAP authentication/authorization module tries to solve the following problems that other such modules may not solve in all cases:
bind call, but is incapable of verifying an SHA1 or crypt
password hash from the directory, as mod_auth_ldap can.
The module also tries to do reduce LDAP connection overhead by caching a connection between requests (one per server record). This is most likely to improve performance in the case of certificate authentication, as for basic authentication a bind to the directory on a new connection is necessary with every request. Future development may add a cache to improve performance.
Version 0.8 added the ability to use the cache built into some client libraries, most notably OpenLDAP. However, it turned out that the cache for OpenLDAP 2.0.7 does not work, and only causes Apache to dump out the contents of BER buffers instead of authenticating users.
mod_authz_ldap uses some functions from libraries that
are only available on Unix systems, it will most probably not work
on a Win32 system. There are no plans to fix this problem.
Of course there are other modules that perform LDAP authentication. Not mentionning them here does not mean that they are insignificant, quite the contrary is true. I just happen to only have used Alex Mayrhofers solution. And as far as I know, none of the available solutions does either certificate mapping or password aging.
The current version can be downloaded from mod_authz_ldap-0.15.tar.gz. The most up to date version can always be found at http://www.othello.ch/software/mod_authz_ldap.html
mod_authz_ldap can be installed either as a dynamic shared
object (DSO) or statically linked into the apache server.
It is recommended to install the module as a DSO, as this mode is much
better tested.
After installation, proceed to the configuration.
configure options
mod_authz_ldap uses configure to explore the
system and set appropriate compiler and linker flags.
There are a number of options available:
--with-debug--with-openssl-path=path-to-opensslconfigure script tries to find the OpenSSL libraries
in /usr/local/ssl.
If you have them installed in some other directory,
you should use this option to help configure find them.
--with-cachesize=cachesize-in-kb--with-timeout=timeout--with-ownerConfigure the package as a DSO
$ ./configure --with-apxs=path-to-apxs
Set LDFLAGS appropriately if your LDAP libraries or not on the standard
library search path. Then compile and install the support programs
$ make
$ su
Password:
# make install
. . .
The module must be compiled with separate Makefile targets:
$ make module
$ su
Password:
# make module-install
. . .
The installation does automatically activate the module in the default
server configuration file. If the module is to be used in servers using
some other configuration file, it should be activated by adding the following
commands to the configuration file:
LoadModule authz_ldap_module libexec/mod_authz_ldap.so
AddModule mod_authz_ldap.c
Even if you decide to install as a statically linked module, you
will have to follow the steps above to compile the support programs
cert2ldap and certfind.
Note also that the static build is not really supported any longer,
but only provided as a start for people unfortunate enough not to
be able to use DSO.
To install as as statically linked module, do the following:
mod_authz_ldap.
configure script
without an --with-apxs option:
# ./configure
This is required to build the authz.h header file.
--enable-module=authz_ldap
to Apache's configuration command.
mod_authz_ldap is configured through a set of directives
on the directory level. In particular, the server creates an LDAP server
connection for each directory configuration. Subsequent requests to
the same directory do not create a new LDAP connection, except when
Basic Authentication is done against the directory, as this is done
through a bind call in a separate connection each time authentication
is necessary.
If mod_authz_ldap should accept that other authorization
modules may grant access to a user although mod_authz_ldap
has denied it, it must be denied authority by the command
AuthzLDAPAuthoritative off
The default is that mod_authz_ldap is authoritative.
Whenever mod_authz_ldap is supposed to authenticate or
authorize (if the user was authenticated by a certificate, only
the authorization part is left to the module) a user, it needs
to contact an LDAP directory. The following directives configure
the directory:
AuthzLDAPServer server[:port]
AuthzLDAPBindDN DN_to_bind_as
AuthzLDAPBindPassword Password_to_bind_with
If no server is configured, a server on the local host on the standard
LDAP port 389 is assumed. If no bind credentials are defined, an
anonymous bind is performed.
User authentication through basic authentication against an LDAP
directory is by default active if AuthName and
AuthType are defined for a directory or location.
It works as follows:
base, a query is performed from the configured user base DN
for a node with the attribute uid set to the name
entered by the user in the login dialog. The user's distinguished
name is set to the distinguished name of the node found, provided
the search returned a single node.
If the user search scope was base, then the distinguished
name is constructed from the userkey (normally uid),
the username from the dialog and the user search base.
require age directive,
the last modification timestamp is checked as configured as
described in section 3.5 on password expiration below.
As one can see, mod_authz_ldap needs additional information
besides the LDAP server
to be able to
AuthzLDAPUserKey UID_attribute_name_in_DN
AuthzLDAPUserBase DN_of_user_subtree
AuthzLDAPUserScope base|onelevel|subtree
The user node in the DIT below the node specified by the
AuthzLDAPUserBase directive is expected to have an attribute
named by the value of AuthzLDAPUserKey, the value
of which is supposed to be the user id from the basic authentication.
The default search scope for a user is base.
In that case, the distinguished name of the user will
be of the form userkey=uid,userbase.
If none of the above values are set, the user must enter his/her
distinguished name in the password dialog.
After successful authentication, the distinguished name of the user is placed in the authorization header. Subsequent authorization modules must therefore be able to deal with a distinguished name as the user id.
A require user directive will search for the user
according to the settings above and verify that exactly one user
is returned an matches the distinguished name obtained from the
LDAP authentication. If the AuthzLDAPUser* attributes
are not set, a require user statement must specify the
full distinguished name of a user.
Certificate mapping tries to find a user based on the subject
and issuer DN. As uniqueness of distinguished names of subjects
across CAs is not guaranteed, only the pair (issuer, subject)
is unique. mod_ssl does not
make the issuer DN directly accessible to other modules (except
to CGIs and SSIs), so some minor modification
is required.
The LDAP server has to be prepared to perform this mapping. It needs to contain nodes of the following type (described here in old openldap version 1 notation):
attribute issuerDN ces attribute subjectDN ces objectclass certificatemap requires objectClass, issuerDN, owner allows subjectDN, serialNumber, userCertificate
Although it looks as both subjectDN and serialNumber can be omitted, one of them is needed (see the discussion of the AuthzLDAPUseSerial directive), but this cannot be expressed in the above syntax. A similar remark applies to the OpenLDAP syntax below.
A definition for the attributes issuerDN and
subjectDN and for the objectclass certificatemap
should be added to the directory server. Openldap version 1 users
can use the file authzldap.slapd.conf file for this purpose, version 2
users will use authzldap.schema. The latter contains official object
IDs.
attributetype ( 1.3.6.1.4.1.4263.5.1 NAME 'issuerDN' DESC 'The user friendly version of the distinguished name of the issuer of a certificate' EQUALITY caseExactIA5Match SYNTAX 1.3.6.1.4.1.1466.115.121.1.40 SINGLE-VALUE ) attributetype ( 1.3.6.1.4.1.4263.5.2 NAME 'subjectDN' DESC 'The user friendly version of the distinguished name of the subject of a certificate' EQUALITY caseExactIA5Match SYNTAX 1.3.6.1.4.1.1466.115.121.1.40 SINGLE-VALUE ) objectclass ( 1.3.6.1.4.1.4263.5.3 NAME 'authzLDAPmap' DESC 'Map Entry for mod_authz_ldap' SUP top AUXILIARY MUST ( issuerDN $ owner ) MAY ( subjectDN $ serialNumber $ userCertificate )
Certificate Mapping searches for a node in a subtree of the directory that has issuerDN and subjectDN as read from the certificate. It is configured through the following directives:
AuthzLDAPUseCertificate on|off
AuthzLDAPUseSerial on|off
AuthzLDAPMapBase base_dn_for_search_for_certificate_dn
AuthzLDAPMapScope base|onelevel|subtree
This only makes sense, if mod_ssl
has been configured to request a client certificate through the SSLRequireSSL
option (see the mod_ssl
documentation for details).
SSLRequireSSL
While earlier releases of this module read the subjectDN from the
basic authentication header, they now read it from the mod_ssl context,
as all the variables used for the mapping.
Last, but not least, it is possible to directly match a user against
her certificate. However, this requires that the directory server is
able to perform an equality match for the userCertificate
attribute.
This is not the case by default in OpenLDAP, but can be enabled by changing
the definition of userCertificate in core.schema.
Change the definition from
attributetype ( 2.5.4.36 NAME 'userCertificate'
SYNTAX 1.3.6.1.4.1.1466.115.121.1.8 )
to
attributetype ( 2.5.4.36 NAME 'userCertificate'
EQUALITY octetStringMatch
SYNTAX 1.3.6.1.4.1.1466.115.121.1.8 )
Strictly speaking, this violates some generally accepted schema
standards, but it is so immensly useful.
mod_authz_ldap can now directly match the certificate if
the directive AuthzLDAPDirect
is enable. In this case, the module performs a search under the
the base specified by
AuthzLDAPUserBase
with scope as set by
AuthzLDAPUserScope
for a user having a userCertificate attribute with the same
certificate as the SSL client supplied.
Note: +FakeBasicAuth is no longer
needed for certificate authentication.
The module finds the subject and issuer distinguished names from
the SSL context, there is no necessity to misuse a fake basic authentication
any longer.
If +FakeBasicAuth is specified, the basic authentication
will simply be overwritten wherever the module is active.
The require group directive in the context of
the mod_authz_ldap module asks to verify membership
of a user in a group defined in the LDAP directory. The group
must be of objectclass groupOfNames, the members
must be defined in member attributes, which have
distinguished names of users as values.
AuthzLDAPGroupBase base_for_onlevel_group_search
AuthzLDAPGroupKey name_attribute_of_group
Groups are expected to have a distinguished name of the form
groupkey=groupkeyvalue,groupbase
A user is accepted if the group has a member attribute
with current user's distinguished name as value.
If neither directive is configured, the require statement must specify the full distinguished name of a group.
Starting with release 0.14, mod_authz_ldap can verify
roles of a user. In the most general form, a role is a required value
of an attribute of the user's node. mod_authz_ldap
simply needs to know the name of the attribute, which can be
specified with the configuration directive
AuthzLDAPRoleAttributeName attrname
If this is set, you can include a directive
require role rolename
in the server configuration file, which will cause a user to be allowed only
if he has an attribute of name attrname with value rolename.
Note that * is a valid value for the role name, this results
in the user being accepted if he simply has that attribute. This can
be used e.g. to accept all users that have a mailbox (if some attribute
contains the name of his mailbox). Substring matches are also possible,
on could accept a user exactly if she has a mailbox in a given domain,
if an attribute mailboxhost contains the mailbox host.
A requirement for a role of the form *.dom.ain will do the
trick.
This generality of the role mechanism can often save you from having to
extend the schema and define a special role attribute.
Even greater generality is offered by the require filter
directive of the form
require filter [ SCOPE ] filter-expression
The SCOPE must be one of the strings
BASE,
ONLEVEL or SUBTREE.
If the word after filter is not one of these strings,
it is assumed that the scope was not specified. In this case, the default
of BASE will be used and the rest of the line is
used as a filter expression.
The requirement succeeds if the filter returns something, it fails if
nothing is returned by the filter, or if the filter causes an LDAP error.
In some applications, it is necessary to base authorization decisions on
file ownership.
Unfortunately, as the apache process runs with rather low privileges,
ordinary access control mechanisms are not suitable.
However, using the ``require owner'' and
``require group-owner'' directives, one can restrict access to
a file to the owner or members of the group of a file.
This model of course assumes Unix file permissions, and is inherently
not portable.
This is why this functionality must be explicitely enabled using
the --with-owner configuration flags.
For password aging, mod_authz_ldap must have a way to
find out the last modification time of the password. The user entry
in the directory needs to have an attribute for that. With OpenLDAP,
the option lastmod on needs to be set in the slapd
configuration file. The configuration directive
AuthzLDAPModifyKey must be specified as follows:
AuthzLDAPModifyKey modifytimestamp
By requireing a maximal age, only users that have modifed their
password recently enough will be accepted:
require age 3.5
This denies users access that have last changed their password more
than 3.5 days ago.
The module can also be used for proxy authentication.
The module will normally recognize automatically whether proxy authentication
or normal authentication is in effect.
In cases where it may not be clear which kind of authentication
is happening, the the flag AuthzLDAPProxyAuthentication
must be set to on for proxy authentication, and to
off for normal authentication.
One such case is a reverse proxy,
which works as a proxy, but authenticates as a server.
The mod_authz_ldap module has its own log level, which is
set by default to LOG_DEBUG. If the log level of the server is set to
debug, all the information available from the module will
be logged to the error log. However, the log information flowing from
the module can be reduced by setting a different log level with the
AuthzLDAPLogLevel directive. Acceptable parameters are
the same as for the LogLevel directive.
When using certificate authentication
(AuthzLDAPUseCertificate set to on),
the basic authentication header is no longer necesary.
However, some applications will still need a user name, which e.g. in
CGI-programms is read from the basic authentication header.
For these programs, the basic authentication header is overwritten
with the distinguished name of the owner of the certificate.
In some cases, e.g. in a reverse proxy authenticating with certificates,
the application may require an additional athentication.
This means that the basic authentication header may not be overwritten
by mod_authz_ldap, which can be prevented with the
directive
AuthzLDAPSetAuthorization off
The default is on.
Two examples show how this module can be used to secure a web server or reverse proxy.
This example describes how mod_authz_ldap can be used to
authorize a user authenticated by an X.509 certificate.
The LDAP server in use is an OpenLDAP
server, for other servers, the preparatory steps (modification of the
shema, user and group definitions) may be different.
addcertmap of
the distribution for this purpose:
ldapadd -c -D cn=root,dc=othello,dc=ch -w secret <<EOF dn: ou=AuthzLDAPCertmap,dc=othello,dc=ch objectclass: top dn: uid=afm,ou=AuthzLDAPCertmap,dc=othello,dc=ch objectclass: top objectclass: authzLDAPmap issuerDN: /C=CH/ST=Schwyz/L=Altendorf/O=Othello/CN=Othello internal CA/Email=ca@othello.ch subjectDN: /C=CH/ST=Schwyz/L=Altendorf/O=Othello/CN=Andreas Mueller/Email=afm@othello.ch owner: uid=afm,ou=People,dc=othello,dc=ch EOF
/confidential
based on the group membership of the user:
<Location /confidential>
SSLRequireSSL
AuthName AuthzLDAP
AuthType Basic
AuthzLDAPServer "localhost:389"
AuthzLDAPUseCertificate on
AuthzLDAPMapBase ou=AuthzLDAPCertmap,dc=othello,dc=ch
AuthzLDAPMapScope onelevel
require valid-user
</Location>
One particularly usefull application of apache and its proxy module is
as a security gateway to an internal web server.
The ProxyPass and ProxyPassReverse directives
in conjunction with the above configuration lead to a secure proxy
gateway to some internal server. Here es an example configuration:
<Location />
SSLRequireSSL
AuthName AuthzLDAP
AuthType Basic
AuthzLDAPServer "localhost:389"
AuthzLDAPUseCertificate on
AuthzLDAPMapBase ou=People,dc=othello,dc=ch
AuthzLDAPMapScope onelevel
require valid-user
</Location>
ProxyPass / http://intrahost.doma.in/
ProxyPassReverse / http://intrahost.doma.in/
This grants a user authenticated through an X.509 certificate and belonging
to the group authz access to the web server on
intrahost.doma.in. Note that you cannot do without the
AuthName
or AuthType directive.
Since the module modifies the basic authentication headers of a request,
a call to the authentication function in a subrequest will find an already
transformed user name, which cannot be authenticated again.
The authentication function only performs authentication for the
initial request. As a consequence, if a subrequest leads to a
directory differently authenticated than the initial request,
the mapping for the subrequest may be incorrect.
However, the authorization is performed so differing require
clauses for the subrequest are handled correctly.
In a large directory, authentication with mod_authz_ldap becomes slow as soon as one of the searches performed is slow. Indexes can improve the performance considerably, the following table shows the attributes that need to be indexed for the various parts of mod_authz_ldap
| Search Type | Attribute | Index Type |
|---|---|---|
| User Search | uid |
equality |
| Group Search | cn |
equality |
| Certificate Mapping | issuerDN |
equality |
subjectDN |
equality |
The module measures the elapsed and the cpu time for each request and logs it in log level debug to the error log. On a 233MHz Pentium, one can see that an immeasurable amount of cpu time is spent in the module (hardly ever more than the 10ms resolution). The elapsed time depends very much on whether this is the first call to the module: during the first call, an LDAP connection is established, which makes take the module around 70ms if the LDAP server resides on the same machine. Subsequent calls to the authorization function usually take just above 1ms, but calls to the authentication function less than 1ms. The performance hit by this module is therefore negligible: a simple directory listing request on the same machine takes around 150ms to complete, so the impact of the module is around 1%.
Even a somewhat dated Sun SPARCstation 10 spends only a few milliseconds in the authentication function, the authorization function is even cheaper.
All this changes for worse if the LDAP server is overloaded or otherwise slow. E. g. if the certificate issuer or subject attribute is not indexed, the search for the owner of the certficate may well be slow.
mod_authz_ldap makes extensive use of ap_log_rerror
to log debug messages to the servers error log. All critical actions
are documented there, and all errors generate an error message.
The first step when debugging mod_authz_ldap is therefore
to raise the server's log level to debug.
If you cannot solve the problem from the debug output, you may send a problem report to the author. Please equip the message with a succinct Subject:-line, or it may get lost between the junk mail messages (if your subject is ``Help'', it may well happen that the message is not read at all).
/etc/ldap.confmod_authz_ldap tries to map the issuer and subject
distinguished name from the certificate to a user distinguished name
in the directory.
mod_authz_ldap uses the certificate, and tries
to match against a userCertificate attribute of the user.
Note that the search starts at the base set by
AuthzLDAPUserBase
with the scope set by AuthzLDAPUserScope,
so both have to be set to some reasonable value.
Note also that equality matching against the userCertificate
attribute is not possible by default in some directory servers, and
violates some generally accepted schema definitions.
mod_authz_ldap uses the certificate's serial
number instead of the subject name to map
the certificate to a user distinguished name
in the directory.
mod_authz_ldap. This would make it impossible
to build a secure reverse proxy authenticating with certificates and still
authenticating to the remote server with basic authentication.
Setting this option to off
disables overwriting the authorization headers.
require role directives.
mod_authz_ldap are final. Sometimes however it is desired to
have other modules do checks if mod_authz_ldap would
deny a request. In these cases, this
option must be set to off.
off forces normal authentication, on
forces proxy authentication.
conigure).
This module is distributed under the terms of the Apache License, please check the LICENSE file in your apache distribution for the exact terms of the license.
